Specification
Dimensions: 48 * 40mm
Temperature control mode: ON / OFF
Temperature range : -50-110 C
Resolution When temperature is 0.1 the resolution is -9.9~99.9, other temperature segment is 1
Control accuracy: 0.1
Hysteresis accuracy: 0.1
Refresh rate: 0.5S
High temperature protection 0-110
Supply voltage: DC 12V
Static current: ≤ 35MA, attract current ≤ 65MA
Output voltage load: DC 12VDC / 230VAC
Output power load: 10A / 15A relay
Measurement input: NTC (10K 0.5%) Waterproof Sensor
Environmental requirements: -10 ~ 60 Humidity 20% -85%
